| Art./Item |  Foro dischi (mm.) | Ø (mm.) |  thickness | Sett.Altezza | Sett. Q.tà | Largh. | Sottotitolo |
|---|---|---|---|---|---|---|---|
| 54411 | 30-25,4 | 350 | 3,2 | 12 | 24 | 40 | cemento da pavimentazione |
| 54412 | 30-25,4 | 400 | 3,2 | 12 | 28 | 40 | cemento da pavimentazione |
| 54413 | 30-25,4 | 450 | 3,6 | 12 | 32 | 40 | cemento da pavimentazione |
| 54414 | 30-25,4 | 500 | 3,6 | 12 | 36 | 40 | cemento da pavimentazione |
| 54415 | 30-25,4 | 600 | 4 | 12 | 36 | 40 | cemento da pavimentazione |
Material
Cured Concrete 🟠🟠🟠
Abrasives/Refractory 🟠🟠🟠
Cutting indications
Dry cut
Humid cut
Technology
Zenith 3D Technology
Zenith 3D technology relies on a particular geometric configuration of the diamond grains that improves the durability and performance of the diamond tool between 30% and 70%.
Laser
Laser welding ensures maximum precision and strength for diamond blades.
Performance
High speed
Blade manufactured with special technologies that make it particularlyfast.
Long life
Grazie alle speciali tecnologie con cui è stato costruito, il disco garantisce una lunga durata di utilizzo.
Height 12 mm
Diamond segment with increased height. Ensures fong life of the blade.
Platinum
Innovative product with aa special design that responds to the most advanced technology and provides additional benefits (low noise, cooling, etc.).
Wet and dry cutting
Zenith Advantages
OSA - EN13236 certified quality
In conventional tool manufacture, cutting speed and tool life are two inversely proportional factors. All manufacturers in the past have aimed to produce diamond tools that combine these two parameters.
Zenith 3D Evolution has surpassed the limit imposed by old technologies by achieving exceptional speed and tool life performance, the result of huge investment in research and in advanced, automated production systems, guaranteeing consistent production standards.
The uniform consumption of the diamond disc allows the tool to be constantly revived, maintaining maximum stability and almost totally eliminating overload and vibration to the operator, especially in manual applications.
Kapriol Power Tools has OSA certification (Organisation for the Safety of Abrasives). OSA marking certifies that the product complies with manufacturing, quality and safety regulations according to EN 13236 and the safety standards in force. This regulation contains all prescriptions and/or safety measures to be taken in order to prevent or reduce dangers deriving from design and use of abrasive/diamond tools.
1. Name of the manufacturer
2. Traceability code
3. Manufacturer identification number
4. Maximum working speed in m/s
5. Maximum rotation speed (rpm
6. Declaration of conformity
7. Restrictions of use
8. OSA Marking
9. Dimensions
10. Direction of rotation
